Cadmium in PDB 1ii0: Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase

Enzymatic activity of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase

All present enzymatic activity of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase:
3.6.3.16;

Protein crystallography data

The structure of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase, PDB code: 1ii0 was solved by T.Zhou, S.Radaev, B.P.Rosen, D.L.Gatti, with X-Ray Crystallography technique. A brief refinement statistics is given in the table below:

Resolution Low / High (Å) 28.61 / 2.40
Space group P 21 21 2
Cell size a, b, c (Å), α, β, γ (°) 76.727, 222.189, 74.126, 90.00, 90.00, 90.00
R / Rfree (%) 21 / 25.2

Other elements in 1ii0:

The structure of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase also contains other interesting chemical elements:

Magnesium (Mg) 4 atoms
Arsenic (As) 2 atoms
Chlorine (Cl) 7 atoms

Cadmium Binding Sites:

Pages:

>>> Page 1 <<< Page 2, Binding sites: 11 - 17;

Binding sites:

The binding sites of Cadmium atom in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase (pdb code 1ii0). This binding sites where shown within 5.0 Angstroms radius around Cadmium atom.
In total 17 binding sites of Cadmium where determined in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase, PDB code: 1ii0:
Jump to Cadmium binding site number: 1; 2; 3; 4; 5; 6; 7; 8; 9; 10;

Cadmium binding site 1 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 1 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 1 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
A:Cd594

b:33.0
occ:1.00
 SG A:CYS172 2.4 34.8 1.0
SG A:CYS113 2.5 31.3 1.0
CL A:CL597 2.6 26.2 1.0
SG A:CYS422 2.6 28.1 1.0
O A:HOH2005 2.6 23.9 1.0
CB A:CYS422 3.5 28.6 1.0
CB A:CYS172 3.6 42.0 1.0
CB A:CYS113 3.6 26.4 1.0
CD A:CD595 3.8 27.5 1.0
O A:HOH2223 3.9 56.4 1.0
CB A:SER420 3.9 30.2 1.0
OG A:SER420 4.1 31.1 1.0
O A:HOH2092 4.2 27.1 1.0
CD A:CD596 4.3 29.3 1.0
N A:CYS113 4.4 25.1 1.0
N A:CYS422 4.5 29.5 1.0
CA A:CYS113 4.6 26.3 1.0
CA A:CYS422 4.7 29.3 1.0
CA A:CYS172 5.0 43.2 1.0
CD A:PRO421 5.0 29.4 1.0

Cadmium binding site 2 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 2 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 2 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
A:Cd595

b:27.5
occ:1.00
 NE2 A:HIS453 2.4 26.8 1.0
O A:HOH2026 2.5 22.1 1.0
CL A:CL598 2.5 30.1 1.0
SG A:CYS172 2.6 34.8 1.0
CL A:CL597 2.6 26.2 1.0
O A:HOH2092 3.1 27.1 1.0
CD2 A:HIS453 3.2 27.6 1.0
CE1 A:HIS453 3.4 27.1 1.0
CB A:CYS172 3.7 42.0 1.0
CD A:CD594 3.8 33.0 1.0
CD2 A:LEU457 4.0 37.4 1.0
CA A:CYS172 4.0 43.2 1.0
CA A:GLY111 4.2 24.6 1.0
O A:HOH2223 4.2 56.4 1.0
CG A:HIS453 4.4 27.4 1.0
ND1 A:HIS453 4.4 27.6 1.0
O A:SER171 4.5 54.3 1.0
O A:GLN108 4.5 28.8 1.0
N A:GLY111 4.5 25.4 1.0
N A:CYS172 4.6 48.3 1.0
CB A:CYS113 4.7 26.4 1.0
C A:SER171 4.7 53.5 1.0
C A:GLY111 4.9 24.6 1.0

Cadmium binding site 3 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 3 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 3 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
A:Cd596

b:29.3
occ:1.00
 O A:HOH3025 2.2 17.8 1.0
OG A:SER420 2.2 31.1 1.0
NE2 A:HIS148 2.3 25.1 1.0
SG A:CYS113 2.6 31.3 1.0
O A:HOH2297 2.6 35.8 1.0
CD2 A:HIS148 3.2 25.3 1.0
CE1 A:HIS148 3.4 24.6 1.0
CB A:SER420 3.5 30.2 1.0
CB A:CYS113 3.5 26.4 1.0
O A:HOH2050 3.8 33.1 1.0
O A:HOH2087 4.0 33.5 1.0
CD1 A:LEU152 4.1 29.4 1.0
CB A:CYS172 4.2 42.0 1.0
CD A:CD594 4.3 33.0 1.0
CA A:SER420 4.4 30.2 1.0
OD1 A:ASP417 4.4 31.3 1.0
CG A:HIS148 4.4 25.5 1.0
ND1 A:HIS148 4.5 25.9 1.0
CA A:CYS113 4.5 26.3 1.0
O A:ASP417 4.8 26.4 1.0
O A:CYS172 4.8 41.1 1.0
SG A:CYS172 5.0 34.8 1.0
CD A:PRO421 5.0 29.4 1.0

Cadmium binding site 4 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 4 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 4 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
A:Cd600

b:22.4
occ:1.00
 OD1 A:ASP320 2.2 18.5 1.0
NE2 B:HIS1585 2.2 24.2 1.0
O A:HOH3026 2.3 15.4 1.0
ND1 B:HIS1587 2.3 20.3 1.0
CL A:CL4000 2.6 22.7 1.0
OD2 A:ASP320 2.6 21.9 1.0
CG A:ASP320 2.7 21.0 1.0
CE1 B:HIS1585 3.1 24.1 1.0
CE1 B:HIS1587 3.2 19.6 1.0
CD2 B:HIS1585 3.3 23.8 1.0
CG B:HIS1587 3.3 21.4 1.0
CB B:HIS1587 3.6 23.3 1.0
O B:HOH2008 3.8 24.3 1.0
O A:ASP320 4.1 20.7 1.0
CB A:ASP320 4.2 20.5 1.0
CA B:HIS1587 4.2 24.7 1.0
ND1 B:HIS1585 4.3 24.3 1.0
NE2 B:HIS1587 4.3 20.4 1.0
CG B:HIS1585 4.4 24.3 1.0
CD2 B:HIS1587 4.4 21.6 1.0
O B:HOH2088 4.6 28.8 1.0
CE1 A:HIS585 4.6 23.2 1.0
O A:HOH2054 4.7 29.8 1.0
C A:ASP320 4.7 20.5 1.0
O A:HOH2034 4.7 20.8 1.0
CA A:ASP320 4.7 20.8 1.0
N B:HIS1587 4.8 24.3 1.0

Cadmium binding site 5 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 5 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 5 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
A:Cd601

b:22.7
occ:1.00
 O A:HOH2034 2.1 20.8 1.0
O A:HOH2010 2.3 16.4 1.0
NE2 A:HIS588 2.3 22.3 1.0
O A:HOH2019 2.3 11.7 1.0
NE2 A:HIS585 2.4 23.3 1.0
O A:HOH2029 2.4 14.4 1.0
CD2 A:HIS588 3.2 21.6 1.0
CE1 A:HIS585 3.3 23.2 1.0
CD2 A:HIS585 3.3 23.2 1.0
CE1 A:HIS588 3.4 22.8 1.0
O A:HOH3000 4.2 19.3 1.0
O A:HOH3001 4.3 23.9 1.0
OD1 A:ASP321 4.4 20.6 1.0
OD1 A:ASP320 4.4 18.5 1.0
CG A:HIS588 4.4 21.9 1.0
ND1 A:HIS588 4.4 22.0 1.0
ND1 A:HIS585 4.5 24.0 1.0
CG A:HIS585 4.5 23.6 1.0
O A:HOH2198 4.5 37.5 1.0
NH2 A:ARG324 4.6 25.1 1.0
OD2 A:ASP321 4.7 20.3 1.0
CG A:ASP321 4.9 20.1 1.0

Cadmium binding site 6 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 6 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 6 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
A:Cd602

b:31.5
occ:1.00
 OE1 B:GLU1326 1.9 33.7 1.0
O B:HOH2009 2.2 24.0 1.0
NE2 A:HIS584 2.3 27.7 1.0
NE2 A:HIS586 2.4 23.1 1.0
OE2 B:GLU1326 2.5 33.9 1.0
CD B:GLU1326 2.5 33.7 1.0
CE1 A:HIS584 3.2 28.0 1.0
CD2 A:HIS586 3.3 22.5 1.0
CD2 A:HIS584 3.3 27.1 1.0
CE1 A:HIS586 3.3 22.7 1.0
CG B:GLU1326 4.0 32.3 1.0
ND1 A:HIS584 4.3 27.3 1.0
CG A:HIS584 4.4 27.2 1.0
CG A:HIS586 4.4 22.6 1.0
ND1 A:HIS586 4.4 22.6 1.0

Cadmium binding site 7 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 7 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 7 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
A:Cd603

b:91.9
occ:1.00
 OE2 A:GLU168 2.5 80.4 1.0
NE2 A:HIS397 2.6 49.8 1.0
OE1 A:GLU168 2.7 79.9 1.0
O A:HOH2120 2.9 40.0 1.0
CD A:GLU168 2.9 80.1 1.0
O A:HOH2160 3.0 50.4 1.0
O A:HOH2145 3.2 34.0 1.0
CE1 A:HIS397 3.4 50.1 1.0
CD2 A:HIS397 3.6 49.2 1.0
O A:HOH2097 3.7 51.5 1.0
CG A:GLU168 4.5 80.0 1.0
ND1 A:HIS397 4.5 49.8 1.0
CG A:HIS397 4.7 49.5 1.0

Cadmium binding site 8 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 8 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 8 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
A:Cd604

b:42.6
occ:1.00
 ND1 A:HIS388 2.3 37.9 1.0
OD1 A:ASP386 2.3 43.9 1.0
OD2 A:ASP386 2.7 44.6 1.0
CG A:ASP386 2.8 43.0 1.0
CG A:HIS388 3.2 38.0 1.0
CE1 A:HIS388 3.3 38.3 1.0
CB A:HIS388 3.4 37.8 1.0
CB A:ASP386 4.3 41.7 1.0
CD2 A:HIS388 4.4 37.8 1.0
NE2 A:HIS388 4.4 38.7 1.0
N A:HIS388 4.6 37.9 1.0
CA A:HIS388 4.6 38.1 1.0

Cadmium binding site 9 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 9 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 9 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
A:Cd605

b:45.6
occ:0.50
 NE2 A:HIS520 2.4 35.9 1.0
O A:HOH2152 2.8 42.2 1.0
CE1 A:HIS520 3.2 36.2 1.0
CD2 A:HIS520 3.5 35.7 1.0
OE1 A:GLU515 3.7 32.3 1.0
ND1 A:HIS520 4.4 35.8 1.0
CG A:HIS520 4.6 35.4 1.0
CD A:GLU515 4.7 31.9 1.0

Cadmium binding site 10 out of 17 in 1ii0

Go back to Cadmium Binding Sites List in 1ii0
Cadmium binding site 10 out of 17 in the Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase


Mono view


Stereo pair view

A full contact list of Cadmium with other atoms in the Cd binding site number 10 of Crystal Structure of the Escherichia Coli Arsenite-Translocating Atpase within 5.0Å range:
probe atom residue distance (Å) B Occ
B:Cd1594

b:28.8
occ:1.00
 CL B:CL1597 2.4 32.0 1.0
SG B:CYS1422 2.4 28.9 1.0
SG B:CYS1172 2.6 43.9 1.0
SG B:CYS1113 2.6 26.9 1.0
O B:HOH2004 2.6 28.8 1.0
OG B:SER1420 3.2 32.1 1.0
CB B:CYS1172 3.5 48.6 1.0
CB B:CYS1422 3.6 29.4 1.0
CB B:CYS1113 3.6 25.2 1.0
CD B:CD1595 3.7 24.5 1.0
O B:HOH2023 4.0 30.5 1.0
CB B:SER1420 4.1 31.8 1.0
CD B:CD1596 4.3 30.9 1.0
N B:CYS1422 4.4 30.5 1.0
N B:CYS1113 4.6 25.7 1.0
CA B:CYS1422 4.6 29.8 1.0
CA B:CYS1113 4.7 25.5 1.0
CL B:CL1598 4.9 24.1 1.0
CA B:CYS1172 5.0 50.0 1.0
CD B:PRO1421 5.0 30.5 1.0

Reference:

T.Zhou, S.Radaev, B.P.Rosen, D.L.Gatti. Conformational Changes in Four Regions of the Escherichia Coli Arsa Atpase Link Atp Hydrolysis to Ion Translocation. J.Biol.Chem. V. 276 30414 2001.
ISSN: ISSN 0021-9258
PubMed: 11395509
DOI: 10.1074/JBC.M103671200
